PTZ Camera Explosion Proof

Models: TR-DF4420-EX(SS304)

The TRANSLOGI TR-DF4420-EX(SS304) is a 4 MP explosion-proof network speed dome camera featuring a 20x optical zoom lens, crafted from highly durable 316L stainless steel with an IP68 rating, specifically designed to meet safety monitoring needs in hazardous areas and harsh environments.

Ex-mark: ATEX: Ex II 2GD Ex db IIC T6 Gb / Ex tb IIIC T80°C Db; IECEx: Ex db IIC T6 Gb / Ex tb IIIC T80°C Db
316L stainless steel
High quality imaging with 4 MP resolution
Supports H.265 video compression
120 dB WDR, 3D DNR
20× optical zoom, focal length 4.8 mm to 96 mm
Water and dust resistant (IP68)

Get pricing

Datasheet

WDR

Equipped with 120 dB Wide Dynamic Range (WDR) technology, allowing the camera to process and maintain clear imaging even in environments with complex lighting or strong back light.

Video Compression

Supports advanced H.265 video compression and highly efficient H.265+ (on the main stream), significantly optimizing network bandwidth and saving storage space.

3D Digital Noise Reduction

Integrates 3D DNR technology to enhance image quality by filtering out grainy noise, delivering smoother and sharper frames.

ALARM

Supports external alarm interfaces (1 input and 1 output) and various smart events such as intrusion detection, line crossing, and unattended baggage detection. Upon an event, the camera can automatically trigger the alarm output, send an email, or notify the surveillance center.

High-Definition

Delivers exceptional high-quality imaging with 4 MP resolution (up to 2560 × 1440 pixels), ensuring every detail is captured clearly.

Infrared

Features infrared capabilities combined with a Day & Night IR cut filter, enabling effective and continuous 24/7 monitoring even in low-light or completely dark conditions.

Key Features

The TRANSLOGI TR-DF4420-EX(SS304) camera stands out with its specialized explosion-proof design to ensure uncompromised safety and durability in high-risk industrial environments. The device is constructed from solid 316L stainless steel and successfully achieves the most stringent global explosion-proof safety certifications, including ATEX and IECEx. Combined with the IP68 protection standard for outstanding water and dust resistance, this camera guarantees reliable operation even in harsh weather conditions and highly volatile environments.
